STANDARD VERSION
Accuracy    :    ±1.0 % of F.S.
Ambient Temperature    :    -25°C to 65°C
Process Temperature    :    Maximum 270°C /Maximum +400°C
        (with SS 316 L internals)
Operating Pressure    :    Maximum 75% of the full Scale Value
Over Pressure Limit    :    Full Scale Value
        30% for pressure ranges < 60 kg/cm2
        25% for pressure ranges = 100 kg/cm2
        15% for pressure ranges     > 100 kg/cm2
Protection    :    IP 65 / IP 55
Bourdon    :    Stainless Steel 316
MOVEMENT    :    Stainless Steel 304
SOCKET MATERIAL    :    Stainless Steel 316
CASE & BEZAL    :    Stainless Steel 304
DIAL    :    Aluminum, Black graduation on
        White background,
POINTER    :    AIuminum BIack CoIoured Micrometer Zero adjustable
WINDOW    :    Glass 4.00mm thick
GASKET    :    EPDM
BLOW OFF DISC    :    EPDM
JOINTS    :    TIG argon are welding

FILLED VERSION

Accuracy    :    ±1.6 % of F.S.
Ambient Temperature    :    Maximum 65°C
Process Temperature    :    Maximum 65°C
Filling Plug    :    EPDM
Window    :    Plexiglass
Damping Liquid    :    Glycerine
Other Features    :    Same as standard version
